36C40X00
Apollo 36C Series Pressure Reducing Valves are designed to protect non-potable water distribution systems by automatically controlling excessive pressure changes. The valves integral thermoplastic cage provides maximum corrosion resistance. Designed for easy in-line servicing with bottom cleanout access to seat disc and strainer.
applications
solutions
approvals
item code | size | weight | dimensions | packaging | gtin + upc |
---|---|---|---|---|---|
36C40303 | 1/2" (DN15) | 2.8 lb | 5x3x6 in | Carton (1 pce) | 00670750427268 |
36C40401 | 3/4" (DN20) | 2.8 lb | 6x3x6 in | Carton (1 pce) | 00670750562570 |
36C40402 | 3/4" (DN20) | 2.8 lb | 6x3x6 in | Carton (1 pce) | 00670750063954 |
36C40403 | 3/4" (DN20) | 2.8 lb | 6x3x6 in | Carton (1 pce) | 00670750326530 |
36C40503 | 1" (DN25) | 3.1 lb | 6x3x6 in | Carton (1 pce) | 00670750293184 |
color | yellow, bronze |
---|---|
materials | bronze (ASTM B584-C84400) |
finishing | none |
manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
shape | straight (0º) |
connection type | FPT - female thread conical (NPT) |
product group | valves (pressure reducing valve) |
---|---|
ETIM class | EC010122 Pressure reducing valve |
country of origin | United States |
brand | Apollo Valves |
series | 36C - Pressure Reducing Valves |
product type | 36C40X00 |
unsps | 40141652 |
label | value |
---|---|
ETIM class | EC010122 Pressure reducing valve |
Housing material | Bronze |
Surface protection | Untreated |
Connection 1 | Internal thread conical (NPT) |
Connection 2 | Internal thread conical (NPT) |
Max. inlet pressure | 27.56bar |
Max. inlet pressure (imperial) | 400psi |
With pressure gauge | No |
Suitable for liquids | Yes |
Suitable for steam | No |
Suitable for gases | No |
Height | 152.4mm |
