36C2PX00
Apollo 36C Series Pressure Reducing Valves are designed to protect non-potable water distribution systems by automatically controlling excessive pressure changes. The valves integral thermoplastic cage provides maximum corrosion resistance. Designed for easy in-line servicing with bottom cleanout access to seat disc and strainer.
applications
solutions
approvals
color | yellow, bronze |
---|---|
materials | bronze (ASTM B584-C84400) |
finishing | none |
manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
shape | straight (0º) |
connection type | FPT - female thread conical (NPT) |
product group | valves (pressure reducing valve) |
---|---|
ETIM class | EC010122 Pressure reducing valve |
country of origin | United States |
brand | Apollo Valves |
series | 36C - Pressure Reducing Valves |
product type | 36C2PX00 |
unsps | 40141652 |
label | value |
---|---|
ETIM class | EC010122 Pressure reducing valve |
Housing material | Bronze |
Surface protection | Untreated |
Connection 1 | Internal thread conical (NPT) |
Connection 2 | Internal thread conical (NPT) |
Max. inlet pressure | 27.56bar |
Max. inlet pressure (imperial) | 400psi |
With pressure gauge | No |
Suitable for liquids | Yes |
Suitable for steam | No |
Suitable for gases | No |
Height | 152.4mm |
