article: SJT400L256

potable water

heating

cooling

compressed air
utility
industry

CRN

NSF
label
value
label
d1
value
2.87
label
DN1
value
2-1/2"
label
l1
value
1.93
label
d2
value
2.87
label
DN2
value
2-1/2"
label
l2
value
1.93
label
M1
value
0.83
label
M2
value
7.56
label
Y
value
1.38
label
V
value
4.37
label
U
value
1.25
color
silver
materials
stainless steel (Stainless steel 316 (1.4401))
finishing
none
connection type
groove (fitting)
pressure rating (PN)
PN 20
sealing
EPDM
product group
valves (butterfly valves)
ETIM class
EC010910 Butterfly valve
country of origin
Taiwan
brand
VSH
series
Shurjoint Stainless Steel
product type
SJ-400L
article
VSH Shurjoint Stainless Steel butterfly valve lever MM 2 1/2" NSF61
article number
SJT400L256
product number with gtin
1V4000025003 (00670750469183)
manufacturer
Shurjoint
item group
SJ-400L - VSH Shurjoint stainless steel butterfly valve lever-operated (2 x groove)
size
2 1/2" w/Lever
weight
7.05 lb
dimensions
9.47x3.11x7.05 "
max operating pressure liquid
290 psi
min. medium temperature
-29 °F
max medium temperature
230 °F
label
value
label
ETIM class
value
label
Material quality
value
Stainless steel 316 (1.4401)
label
Surface protection
value
Untreated
label
Material quality valve butterfly
value
Stainless steel 316 (1.4401)
label
Nominal diameter
value
DN 65
label
Outer pipe diameter all connections
value
73mm
label
Outer pipe diameter all connections (imperial)
value
2.87"
label
Connections
value
Groove
label
Operation
value
Lever handle
label
Sealing
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Length of connection 1
value
49mm
label
Length of connection 1 (imperial)
value
1.93"
label
Length of connection 2
value
49mm
label
Length of connection 2 (imperial)
value
1.93"
label
Height operating element
value
35mm
label
Height operating element (imperial)
value
1.38"
label
Length operating element
value
192mm
label
Length operating element (imperial)
value
7.56"
label
Medium temperature (continuous)
value
-34°C - 110°C
label
Medium temperature (continuous) (imperial)
value
-29.2°F - 230°F
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
VdS quality mark
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
Gastec QA - AR 214 (H2)
value
No
