Apollo High Capacity Lead Free Pressure Reducing Valves with Y-Strainer (2 x FNPT)

Apollo High Capacity Lead Free Pressure Reducing Valves with Y-Strainer (2 x FNPT)


The Apollo Valves 36HLF Series Lead Free Pressure Reducing Valve is designed for commercial, industrial, and institutional applications to reduce incoming water pressure for protection of plumbing system components and to reduce water consumption. The valve is made with proven ASTM grade Lead Free bronze and stainless steel materials. The PRH-LF provides high capacity flow with low pressure drop. It is designed with an integral by-pass relief to protect against thermal expansion downstream. The bottom access enables easy in-line cleaning or seat replacement.

  • Dezincification Resistant Lead Free Bronze
  • Sealed Spring Cage for Vault Installations
  • Ultra-High Flow Capacity
  • Internal Thermal Expansion Bypass
  • Standard Factory Setting: 50 psi
  • Three Spring Ranges: 10 - 125 psi
  • Stainless Steel Bolts and Spring
  • In-line Y-Strainer
  • 100% Made in the USA


potable water


building installations industry


ASSE 1003 CSA B356 NSF
item code size weight dimensions packaging gtin + upc
36HLF21301 1/2" (DN15) 7.7 lb 8x4x9 in Carton (1 pce) 00670750752377
36HLF21302 1/2" (DN15) 7.7 lb 8x4x9 in Carton (1 pce) 00670750752513
36HLF21303 1/2" (DN15) 7.7 lb 8x4x9 in Carton (1 pce) 00670750026614
36HLF21401 3/4" (DN20) 9 lb 9x4x9 in Carton (1 pce) 00670750751868
36HLF21402 3/4" (DN20) 9 lb 9x4x9 in Carton (1 pce) 00670750752353
36HLF21403 3/4" (DN20) 9 lb 9x4x9 in Carton (1 pce) 00670750752520
36HLF21501 1" (DN25) 12 lb 10x5x12 in Carton (1 pce) 00670750751875
36HLF21502 1" (DN25) 12 lb 10x5x12 in Carton (1 pce) 00670750752568
36HLF21503 1" (DN25) 12 lb 10x5x12 in Carton (1 pce) 00670750779039
36HLF21601 1-1/4" (DN32) 29 lb 13x7x13 in Carton (1 pce) 00670750776892
36HLF21602 1-1/4" (DN32) 29 lb 13x7x13 in Carton (1 pce) 00670750595813
36HLF21603 1-1/4" (DN32) 29 lb 13x7x13 in Carton (1 pce) 00670750264528
36HLF21701 1-1/2" (DN40) 29 lb 13x7x14 in Carton (1 pce) 00670750757457
36HLF21702 1-1/2" (DN40) 29 lb 13x7x14 in Carton (1 pce) 00670750209154
36HLF21703 1-1/2" (DN40) 29 lb 13x7x14 in Carton (1 pce) 00670750870347
36HLF21801 2" (DN50) 40 lb 16x8x17 in Carton (1 pce) 00670750752575
36HLF21802 2" (DN50) 40 lb 16x8x17 in Carton (1 pce) 00670750757433
36HLF21803 2" (DN50) 40 lb 16x8x17 in Carton (1 pce) 00670750200533
36HLF21901 2-1/2" (DN65) 49 lb 18x8x19 in Carton (1 pce) 00670750979903
36HLF21903 2-1/2" (DN65) 49 lb 18x8x19 in Carton (1 pce) 00670750672996
36HLF21001 3" (DN80) 99 lb 21x10x22 in Carton (1 pce) 00670750757471
36HLF21003 3" (DN80) 99 lb 21x10x22 in Carton (1 pce) 00670750383588
color yellow, bronze
materials bronze (C89836 (lead-free))
finishing none
manufacturer Aalberts integrated piping systems Americas, Inc. (Apollo)
shape straight (0º)
connection type FPT - female thread conical (NPT)
product group valves (pressure reducing valve)
ETIM class EC010122 Pressure reducing valve
country of origin United States
brand Apollo Valves
series 36HLF - Pressure Reducing Valves
product type 36HLF21X00
unsps 40141652
label value
ETIM class EC010122 Pressure reducing valve
Housing material Bronze
Surface protection Untreated
Connection 1 Internal thread conical (NPT)
Connection 2 Internal thread conical (NPT)
Max. inlet pressure 27.56bar
Max. inlet pressure (imperial) 400psi
With pressure gauge No
Suitable for liquids No
Suitable for steam No
Suitable for gases No
