3314001
The Apollo® Model 120S (33 Series) Globe Valve provides a cost effective “Made in the USA” alternative to globally sourced multi-turn valves. These valves are cast, machined, assembled, and tested in South Carolina. The Apollo® Globe valve can reliably be installed in most plumbing and heating systems (or building service piping).
applications
solutions
approvals
item code | size | weight | dimensions | packaging | gtin + upc |
---|---|---|---|---|---|
3314301 | 1/2" (DN15) | 1.06 lb | 3x2x4 in | Carton (1 pce) | 00670750608216 |
3314401 | 3/4" (DN20) | 1.91 lb | 4x2x6 in | Carton (1 pce) | 00670750606977 |
3314501 | 1" (DN25) | 2.88 lb | 5x2x7 in | Carton (1 pce) | 00670750618062 |
3314601 | 1-1/4" (DN32) | 7.32 lb | Carton (1 pce) | 00670750661938 | |
3314701 | 1-1/2" (DN40) | 6.86 lb | 6x3x9 in | Carton (1 pce) | 00670750660603 |
3314801 | 2" (DN50) | 10.63 lb | 7x4x10 in | Carton (1 pce) | 00670750655531 |
color | yellow |
---|---|
materials | bronze (ASTM B62) |
manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
connection type | solder |
product group | valves (globe valve) |
---|---|
ETIM class | EC010120 Globe valve |
country of origin | United States |
brand | Apollo Valves |
series | 33 - Globe Valves |
product type | 3314001 |
unsps | 40141611 |
label | value |
---|---|
ETIM class | EC010120 Globe valve |
Housing material | Bronze |
Connection 1 | Soldered sleeve |
Connection 2 | Soldered sleeve |
Suitable for liquids | Yes |
Suitable for gases | No |
Suitable for steam | Yes |
VdS quality mark | No |
KIWA certified | No |
Gastec QA mark | No |
