19KJGA000Q
ASME Sections I & VIII capacity certified safety valve for overpressure protection of steam power boilers, pressure piping systems, pressure vessels, piping and similar equipment. Suitable for steam, air and non-hazardous gases.
applications
solutions
approvals
item code | size | weight | dimensions | packaging | gtin + upc |
---|---|---|---|---|---|
19KJGA170Q | 1-1/2" (DN40) x 2-1/2" (DN65) | 19.2 lb | Carton (1 pce) | 00670750360299 | |
19KJGA70Q | 1-1/2" (DN40) x 2-1/2" (DN65) | 19.2 lb | Carton (1 pce) | 00670750600128 | |
19KJGA200Q | 1-1/2" (DN40) x 2-1/2" (DN65) | 19.2 lb | 00191988088576 |
item code | size | DN1 | DN2 |
---|---|---|---|
19KJGA170Q | 1-1/2" (DN40) x 2-1/2" (DN65) | DN40 | DN65 |
19KJGA70Q | 1-1/2" (DN40) x 2-1/2" (DN65) | DN40 | DN65 |
19KJGA200Q | 1-1/2" (DN40) x 2-1/2" (DN65) |
color | yellow, bronze |
---|---|
materials | bronze, brass (ASTM B16, ASTM B584-C84400) |
finishing | none |
manufacturer | Aalberts integrated piping systems Americas, Inc. (Apollo) |
connection type | FPT - female thread conical (NPT) |
product group | valves (safety relief valve) |
---|---|
ETIM class | EC011311 Safety valve |
brand | Apollo Valves |
series | 19 - Safety Relief Valves |
product type | 19KJGA000Q |
label | value |
---|---|
ETIM class | EC011311 Safety valve |
Connection 1 | Internal thread conical (NPT) |
Connection 2 | Internal thread conical (NPT) |
Height | 0mm |
Suitable for heating | No |
Suitable for cooling | No |
Suitable for solar heating | No |
Suitable for hot tap water | No |
