ASME Section IV Capacity Certified Bronze Safety Relief Valves protect ASME Section IV hot water heating boilers and hydronic heating systems. High capacity design features corrosion resistant construction. Brass, satin or polished chrome finishes available. Proudly made in the USA.
|item code||size||weight||dimensions||packaging||gtin + upc|
|1030169||3/4" (DN20)||1.14 lb||3x3x4 in||Carton (1 pce)||00670750492242|
|10301A1||3/4" (DN20)||1.14 lb||3x3x4 in||Carton (1 pce)||00670750357473|
|1030170||3/4" (DN20)||1.14 lb||3x3x4 in||Carton (1 pce)||00670750492259|
|1030174||3/4" (DN20)||1.14 lb||3x3x4 in||Carton (1 pce)||00670750492297|
|1030175||3/4" (DN20)||1.14 lb||3x3x4 in||Carton (1 pce)||00670750492303|
|1030176||3/4" (DN20)||1.14 lb||3x3x4 in||Carton (1 pce)||00670750492310|
|materials||bronze (ASTM B584-C84400)|
|manufacturer||Aalberts integrated piping systems Americas, Inc. (Apollo)|
|connection type||MPT - male thread conical (NPT), FPT - female thread conical (NPT)|
|product group||valves (safety relief valve)|
|ETIM class||EC011311 Safety valve|
|country of origin||United States|
|series||10-300 Safety Relief Valves|
|ETIM class||EC011311 Safety valve|
|Connection 1||External thread conical (NPT)|
|Nominal diameter connection 1||3/4 inch (20)|
|Outer pipe diameter connection 1||26.67mm|
|Outer pipe diameter connection 1 (imperial)||1.05"|
|Connection 2||Internal thread conical (NPT)|
|Nominal diameter connection 2||3/4 inch (20)|
|Outer pipe diameter connection 2||26.67mm|
|Outer pipe diameter connection 2 (imperial)||1.05"|
|Max. operating pressure at 20 °C||4.14bar|
|Max. operating pressure at 20 °C (imperial)||60psi|
|Medium temperature (continuous)||0°C - 121°C|
|Medium temperature (continuous) (imperial)||32°F - 249.8°F|
|Length of connection 1||46.99mm|
|Length of connection 1 (imperial)||1.85"|
|Length of connection 2||36.07mm|
|Length of connection 2 (imperial)||1.42"|
|Suitable for heating||Yes|
|Suitable for cooling||No|
|Suitable for solar heating||No|
|Suitable for hot tap water||No|
